Hook lift bins-Heavy duty

Hook Lift Bins manufacture
Roll on /Roll off Hook Lift Bins
@ Realistic prices

Hook lift bins, Roll on roll off hook lift bins.

comply with the requirements of Australian Standards EN 12079

All our Hook lift bins/ Marrel skip with crane lift  are certified and Tagged





We are a fully Australian owned company  manufacturing of a wide range of Hook lift bins that ranges from 6M3 to 30M3.

with our own factories in China, Taiwan we offer impeccable heavy reinforced   Hook Lift Bins @ realistic  CNF prices (cost and freight) to any port in Australia or New Zealand.

CLICK HERE TO LEASE/ FINANCE  SKIP BIN



HEAVY DUTY HOOK BIN WITH CRANE EYELET'S

HEAVY DUTY HOOK BIN WITH CRANE EYELET’S





HEAVY DUTY HOOK BIN WITH RATCHET SAFETY LOCK

HEAVY DUTY HOOK BIN WITH RATCHET SAFETY LOCK



12M3 HEAVY DUTY HOOK BIN

12M3 HEAVY DUTY HOOK BIN


HEAVY REINFORCED HOOK LIFT BIN

HEAVY REINFORCED HOOK LIFT BIN











8m3 hook lift bin with barn door

8m3 hook lift bin with barn door


 hook lift bin with barn door

Hook lift bin with barn door


Hook lift bins

Hook lift bins


6m3 hook lift bin

6m3 hook lift bin

12M3 HEAVY DUTY HOOK BIN
heavy reinforced hook lift bin with barn door
10m3 heavy reinforced hook lift bin with barn door
10 m3 heavy reinforced hook lift bin with barn door
10m3 heavy reinforced hook lift bin with barn door
HEAVY DUTY HOOK BIN WITH RATCHET SAFETY LOCK
heavy reinforced hook lift bin with barn door
8m3 heavy reinforced hook lift bin with barn door
heavy reinforced hook lift bin with barn door
heavy reinforced hook lift bin with barn door
HEAVY REINFORCED HOOK LIFT BIN
8m3 heavy reinforced hook lift bin with barn door
8m3 heavy reinforced hook lift bin with barn door
heavy reinforced hook lift bin with barn door
30m3 Hook lift bin
HEAVY DUTY HOOK BIN WITH CRANE EYELET'S
10m3 heavy reinforced hook lift bin with barn door
8m3 heavy reinforced hook lift bin with barn door
heavy reinforced hook lift bin with barn door
30m3 Hook lift bin with barn door

Hook Lift Bin Specifications :

Description Weight(Kgs)                 Plates A frame Bottom rails
Internal size(L*W*H)(mm) Side(mm) Floor(mm)
6M 1630 Fabricated 3600*2010*840 5 5 220 PFC 200 PFC
8M 1880 Fabricated 4500*2010*885 5 5 220 PFC 200 PFC
10M 2080 Fabricated 5100*2010*990 5 5 220 PFC 200 PFC
12M 2250 Fabricated 5400*2010*1125 5 5 220 PFC 200 PFC
15M 2500 Fabricated 5400*2010*1400 5 5 220 PFC 200 PFC
20M 2930 Fabricated 5600*2010*1800 5 5 220 PFC 200 PFC
25M 3330 Fabricated 5600*2010*2225 5 5 220 PFC 200 PFC
30M 3650 Fabricated 6660*2010*2225 5 5 220 PFC 200 PFC

HEAVY DUTY HOOK LIFT BINS :

12M3 HEAVY DUTY HOOK BIN

12M3 HEAVY DUTY HOOK BIN

(1)The bottom rails and A frame 220*80*9mm
(2)The bottom rails faces outwards
(3) Barn door with a 10 mm plate under the door to prevent the door from sagging
(4)Barn door with a safety ratchet Lock
(5)heavy duty construction Top rail RHS 100*100*4MM — Side rail RHS 100*100*4mm
(9) Crane lift eyelet’s @30mm thick (Triple pass welds) Tagged and certified in Australia

(8) Hook pin 50mm solid(Triple pass welds) Tagged and certified in Australia
(9)Hook height from ground to underside of lift pin 1470mm or as per your specifications

(10) Tie rails 32*2mm pipe
(11) 2 under coats etched primer +2 top coats with your corporate logo
(12) Reinforcement under the frame and on the side of the walls of the bins
(13) Reinforced A frame 10mm plates



———————————————————————————————————————————————————————————————————-

Our fully fabriacted Hook lift skips are:

  • 4mm floor/5mm
  • 3mm sides/4mm
  • 3mm end walls/4mm
  • custom floor and side wall thickness available
  • mixed skip sizes in a 20ft or 40 ft CTN loads.(eg:3M3,6M3,7M3,9M3)
  • CNF(cost and freight) prices in A$, with assistance in clearing and forwarding to your location
  • Rigid under floor support
  • available with wheel barrow doors
  • 75x50x4mm RHS top rail
  •  Heavy duty reinforced sub frame
  • Custom fabricated rail widths
  • Custom fabricated Hook heights
  • fully seam welded inside and outside
  • 2 coats of  epoxy under coat and 2 top coats painted to customers desired colour
  • heavy duty castors with brake options
  • logo printing on the skips
  • assistance in clearing and forwarding your container to your door step (enquire here)
  • custom heavy duty sided also available
  • we fabricate  skip bins  for commercial or construction applications
  • we manufacture skips to any design and specifications
